The ZPL will override any applied printer settings. Ensure to remove ZPL configuration commands such as darkness, print width, etc.
Print amazon lable with zebra gx430t driver#
Ensure that there is no left position/adjustment set in the driver or on the printer that may move the print horizontally.Printing too far left on the label and cut-off or compressed on the right.Īccess the printing preferences of your driver to adjust settings. If label settings are held within your application, ensure to replicate the settings there. Ensure the setup of the label within your application is correct.Ensure that there is no left position or adjustment set in the driver or on the printer that may move the print horizontally.Ensure that the application matches the print width required for the label.
This can be an LCD Display setting or a button flash function on a desktop.
Ensure that the print width is properly set on the printer. Printing too far right on the label and cut-off or truncated on the right.Īccess the printing preferences of your driver to adjust the settings. If label settings are held within your application, ensure to replicate the settings there. Ensure that there are no unprintable areas set within the driver or application. Ensure that there are no offsets. This may push the label objects incorrectly down within the label. If label settings are held within your application, ensure to replicate the settings there. Printing too low on the label and cut-off or truncated at the bottom.Īccess the printing preferences of your driver to adjust the settings. Ensure that there are no unprintable areas set within the driver or application including margins and gutters. A setting of continuous media when receipt type media is not being used is a common cause of this issue. Drifting of print may occur in that instance. Ensure media type or tracking mode is properly set (gap/notch or mark sensing). Ensure that the width and height settings of the driver and application are properly set. The Label Top compensates for printer vertical position tolerances.
Ensure the Label Top is properly adjusted.Printing too high on the label and cut-off or truncated at the top.Īccess the printing preferences of your driver to adjust settings.
Using Printer Configurations and Settings. Using Printer Programming Language (ZPL). Here are examples of image positioning issues and suggested resolution using the following printing methods: There should be consistent label-to-label positioning before making any adjustments. In addition, before making adjustments or setting changes, ensure your printer has been properly calibrated for the labels being used. If only one object or field is being shifted, you should address the corrective action in your program or label creation application. NOTE Typically, you will see the entire label content being shifted in the problem direction. Learn the issues that relate to incorrect configuration of the Zebra Driver, incorrect ZPL Programming Language, or printer configuration settings. This document will reference the common mistakes that a user may make related to the printer or application/driver that impacts the image position. The variety of ways labels can be created prevents a specific discussion on every method or speak to specific resolutions. The 0 x and 0 y positions are in the upper left-hand corner of the label as noted above unless the orientation is inverted. This placement uses x, y coordinates (x = horizontal, y = vertical) that are like an address positioning the image in memory as it is constructed in the printer memory in preparation for printing. The label objects are positioned on the label using ZPL language coordinates and image fields. IMPORTANT! Regardless of the image orientation on the label references to top, bottom, left, or right are as shown in this picture. What causes incorrect printing location on the label? Applicable ToĪll ZPL compatible Printers Resolution / Answer
